ASME B16.47 Flanges: Large-Diameter Solutions for Industrial Applications

ASME B16.47 flanges are designed for large-diameter piping systems that require reliable and durable connections under high-pressure and high-temperature conditions. These flanges comply with the stringent ASME B16.47 standard, ensuring safety and performance in demanding industrial environments. Kwality Steelage Pvt. Ltd., based in Mumbai, India, is a leading manufacturer of ASME B16.47 flanges, catering to global markets in the Middle East, Africa, Asia, Europe, and the Americas.

Table of Contents

ASME B16.47 Flanges
Send Enquiry
Whatsapp

Table of Contents

Send Enquiry
Whatsapp

Call Us

+91 88792 51118

Email Us

[email protected]

ASME B16.47 Flanges

What Are ASME B16.47 Flanges?

ASME B16.47 flanges are specifically engineered for pipes with a nominal size of 26 inches to 60 inches. These flanges are available in two series: Series A and Series B. While Series A flanges are thicker and heavier, making them suitable for higher-pressure applications, Series B flanges are lighter and designed for systems with lower pressure requirements. Both series ensure secure and leak-proof connections in industrial piping systems.

What Are ASME B16.9 Flanges?

Designed for Large-Diameter Pipes

  • Tailored for nominal pipe sizes (NPS) from 26 to 60 inches.
  • Provides robust connections for large-scale industrial operations.

High-Pressure and High-Temperature Tolerance

  • Handles extreme pressure and temperature conditions with ease.
  • Ensures safety and reliability in critical applications.

Compliance with ASME Standards

  • Meets ASME B16.47 specifications for Series A and Series B flanges.
  • Guarantees compatibility and standardization across global piping systems.

Types of ASME B16.47 Flanges

Weld Neck FlangeWeld Neck Flanges

  • Features a long tapered hub for structural reinforcement.
  • Ideal for high-pressure and high-temperature environments.

Read More

Slip-On-FlangeBlind Flanges

  • Used to seal off the end of a piping system.
  • Provides reliable isolation for maintenance and testing.

Read More

Slip-On-FlangeSlip-On Flanges

  • Suitable for lower-pressure applications.
  • Simplifies installation and alignment.

Read More

Applications Across Industries

Oil and Gas

  • Widely used in refineries, pipelines, and offshore platforms.
  • Ensures secure connections in high-pressure systems.

Power Generation

  • Applied in steam, cooling water, and condensate systems.
  • Ensures durability in thermal and nuclear power plants.

Chemical Processing

  • Resistant to corrosion and extreme temperatures.
  • Used in chemical reactors and large-diameter pipelines.

Water Treatment

  • Suitable for desalination plants and municipal water systems.
  • Provides reliable performance in high-flow systems.

Infrastructure Projects

  • Essential for large-scale piping in industrial facilities and power plants.
  • Offers durability and reliability for long-term operations.

Material Options and Standards

Material Choices

  • Carbon Steel: Cost-effective and durable for standard applications.
  • Stainless Steel: High corrosion resistance for aggressive environments.
  • Alloy Steel: Enhanced strength and performance in extreme conditions.
  • Specialty Alloys: Inconel, Monel, and Hastelloy for niche applications.

Compliance with Global Standards

Standard Description
ASME B16.47 Large-diameter steel flanges.
ASME B16.5 Pipe flanges and flanged fittings.
EN 1092-1 European standard for steel flanges.
DIN Standards German specifications for flange designs.

Dimensional Standards and Design Specifications

  • Outer Diameter: Tailored for large-diameter piping systems.
  • Bolt Circle Diameter: Ensures secure and precise connections.
  • Pressure Ratings: Available in Class 75, 150, 300, 400, 600, and higher.
  • Face Types: Raised Face (RF), Flat Face (FF), and Ring-Type Joint (RTJ).

Benefits of ASME B16.9 Flanges

Reliable Performance

  • Leak-proof connections ensure system integrity.
  • Withstands high-pressure and high-temperature environments.

Cost Efficiency

  • Long-lasting materials reduce maintenance and replacement costs.
  • Simplifies installation and alignment, saving time and labor.

Global Compatibility

  • Designed to meet international standards for seamless integration.
  • Suitable for diverse industrial applications.

Comparison with Other Flanges

Feature ASME B16.47 Flanges ASME B16.5 Flanges Slip-On Flanges
Bore Large-diameter pipes Standard dimensions Fits over pipe
Application High-pressure systems Low to high-pressure systems Low-pressure systems
Installation Welded or bolted Bolted connection Fillet welded
Typical Industries Oil & gas, power plants HVAC, water treatment Petrochemicals, HVAC

Why Choose Kwality Steelage?

  • Precision Manufacturing: High-quality flanges built to ASME B16.47 standards.
  • Global Reach: Exporting to key markets in the Middle East, Africa, Asia, Europe, and the Americas.
  • Custom Solutions: Tailored designs to meet specific industrial requirements.
  • Expert Support: Comprehensive technical assistance and after-sales service.

Pricing Factors

The cost of ASME B16.47 flanges depends on:

  • Material Selection: Stainless steel and specialty alloys are priced higher than carbon steel.
  • Size and Pressure Ratings: Larger sizes and higher pressure classes increase costs.
  • Customization: Non-standard designs may involve additional charges.

Typical price ranges:

  • Carbon Steel ASME B16.47 Flanges: $100 – $500.
  • Stainless Steel ASME B16.47 Flanges: $500 – $1500.
  • Specialty Alloys: $1500 and above

Exporting to Global Markets

Kwality Steelage supplies ASME B16.47 flanges to key international markets:
